CB-6023
FPV Killer Shield
Dismounted Handheld FPV Jammer
Ultra-Lightweight <1.6kg
One-Hand Carry
Detailed Introduction
This SDR-based jamming equipment effectively blocks DIY FPV drone control signals, protecting soldiers from FPV attacks. Compact and lightweight for easy portability, it features one-touch operation enabling rapid single-soldier deployment against suicide FPV threats.
Individual Portable: Compact and lightweight with one-touch operation for instant single-operator defense against suicide FPV drones.
Efficient Jamming FPVs: Utilizing digitally modulated jamming codes, it effectively jams all FPV types, covering mainstream protocols like ELRS and TBS Crossfire.
Long Working Hours: Standard lithium battery powered with quick-swap capability for operational convenience.
Specifications
| Item | Description |
| Jamming mechanism | SDR (Software Defined Radio) |
| Jamming models | DIY FPV drones (Supporting ELRS/TBS Crossfire & major control protocols) |
| Jamming angle | Directional jamming, horizontal 60o, tilt 30o |
| Jamming distance | > 150m (open environment) |
| Total transmission power | < 35W |
| Response time | < 2s |
| Size | 195*205*115mm (±5mm) |
| Weight | < 1.6kg (without batteries) |
| Power consumption | < 100W (full power transmission) < 5W (standby mode) |
| Power supply / Charging | 21700 chargeable lithium batteries powered; Support batteries replacement, and whole machine charging |
| Single battery life | > 30 min per time (full power transmission) |
| Protection level | IP54 |
| Working temperature | -30℃ ~ +45℃ |
Note: Data may vary due to different environments and test targets.Updates will not be separately notified.
AIRCOHN has the final interpretation rights for the relevant content.
